Printers                                                                           Applications
                                                                             Light Industrial       Warehouse




          CP103

          Features
            Windows® Driver                   Data Bits–  Fixed at eight
            POS Compatible                    Double High, Double Wide
           Construction– ABS plastic            Capable
                                               RS-232
           Power–12 volt DC or  AC adapter
             or DC power cable (not included)   Time and Date Standard
           Configurable Baud–                 Customize Logo Affixation
             1200 -115,200                     Invert Printing


          Specifications


          Serial RS-232                                        Number of Columns: 24 or 32
                                                                 *Configuration cable "AWT05-508092 (included)
          Factory Default: 9600, 8, N, 1*
             *Configuration cable AWT05-508092 needed to change configuration  Operating Current: >2 AMP
          Paper Width: 2.3" / 58.4 mm                          Operating Temperature: 41° F to 104° F / 0° C to 50° C
          Print Speed: 90 mm / s max                           Printer Dimension (L x W x H):
                                                                 4" x 3" x 1.8" / 104 mm x 75 mm x 48 mm
          Paper Out Sensor
                                                               Product Weight: 0.32 lb / 0.15 kg
          Data Buffer: 10K
          Resolution: 8 dot/mm (203 dpi)

                                                                                                     Ship
           Part Number   Description                                                                Weight
           816965005727  3″ / 75 mm wide, thermal printer                                             1 lb
           Accessories / Options

                                                                                                     Ship
           Part  Number  Description                                                                Weight
           AWT05-100573 12 VDC US adapter                                                            1 lb
           AWT05-508093 RS-232 communication cable with tinned leads                                 0.5 lb
           AWT25-501226 Direct DC power cable                                                        0.1 lb
           AWT05-508092 RS-232 configuration cable to DB9                                            0.5 lb
           AWT25-501825 CP103 to York Chiller cable                                                  0.5 lb
           AWT25-501826 CP103 to 15-pin D sub (Agricultural indicators)                              0.5 lb
           AWT05-508096 CP103 to Digi Star Kit (see price sheet for kit details)                     3 lb
           AWT05-508097 CP103 to eight pin AMP connector (Agricultural indicator) kit (see price sheet for kit details)  3 lb
           816965006465  1200 baud (9600 selectable) CP103 with mod for always ON (see price sheet for kit details)  3 lb
           AWT05-507979 Paper rolls, 10 rolls per box                                                4 lb
