Counting/Coin Scale Applications
Coin Counting Parts Counting
Light Industrial

B140
Features ®

COMPONENT
 Accuracy– Within ±0.01%  Power– 12 VDC 0.5A adapter with
 Capacity– rechargeable battery at 20 hours
6 kg x 0.2 g / 12 lb x 0.0005 lb battery life between charges (both
15 kg x 0.5 g / 30 lb x 0.01 lb included)
30 kg x 1 g / 60 lb x 0.002 lb  Display– Three six digit 14.2 mm /
0.56" high seven segment red LED
 Construction– Rugged ABS base, with three brightness levels
stainless steel weight platter
 *Currency Feature Added (30
kg / 60 lb only)– US Dollars, GB
Pounds and Euros with big and
small bag selection

Specifications

Unit/*Currency: Units used to switch displayed weights Enter/Pcwt: Enter used to confirm or save entered data
between kg and lb. Currency used to switch between from keyboard. Pcwt used for keyboard entry of a known
currency type (available in 30 kg/60 lb capacity only) average piece weight
Minimum Piece Weight: Tare: Used to zero off (up to 100% of capacity) an empty
6 kg (0.05 g) 12 lb (0.0001 lb) container or weight, not required in the calculation of an
15 kg (0.1 g) 30 lb (0.0002 lb) average piece weight. Use of tare will reduce the scales
30 kg (0.2 g) 60 lb (0.0005 lb) maximum weight capacity by value stored
Power: Internal rechargeable battery giving 20 hours of use Total: Ability to add the display to an accumulator (Memory
between charges. Recharge time approximately eight +) and only accumulate when there is a percentage of
hours with 12 volt UK/EU/US power adapter with center weight change
positive (included).
Clear/Hi/Lo: Clear to erase a keyed in value from the
Battery: 6V4A/Hr rechargeable lead-acid battery display if an error has been made. Hi/Lo is to set the
upper and lower limits.
Auto Off: Selectable between one and 30 minutes or off
Upper: Used to set an upper limit quantity for count check
Configurable RS-232
Lower: Used to set lower limit quantity for count check
Configurable Scale ID
On/Off: Used to turn off display for extended battery life or
Average Working Current: < 300mA reset the scale to normal weighing mode
Operator Keys: On/Off, clear, enter, zero, tare, total, Print: Output to RS-232 communications
kg/lb, piece weight, PLU, print, *currency, upper limit,
lower limit and 0 – 9 for data entry *Mode: Toggle between counting functions
Annunciators: Zero, tare, AC mains connected, battery Operating Temperature: -10° C to 40° C / 14° F to 104° F
charging, stable, big bag, small bag, kg and lb
Scale Dimension (L x W x H):
Counting /Coin Scale
Keyboard Functionality: 0-9– Used for keyboard entry 393 mm x 292 mm x 109 mm / 13.1" x 11.5" x 4.3"
of piece weight, sample size, and upper and lower limit
settings Platform Dimension (L x W x H):
222 mm x 292 mm x 13 mm / 8.75" x 11.5" x 0.5"
Zero: Return displayed weight and count to zero for
accurate weighing and counting. Zero range capability Packaging Dimension (L x W x H):
is 5% of scale capacity. 406 mm x 356 mm x 203 mm / 16" x 14" x 8"
Certifications: UKCA, CE, CEC, FCC compliant, Prop 65,
RoHS 3, ETL power adapter, WEEE
Ship
Part Number Capacity Weight
816965005758 6 kg x 0.2 g / 12 lb x 0.0005 lb 5 kg
816965005765 15 kg x 0.5 g / 30 lb x 0.001 lb 5 kg
816965005772 *30 kg x 1 g / 60 lb x 0.002 lb 5 kg
*30 kg / 60 lb capacity counting/coin scale
