Applications Crane Scales
General Purpose Warehouse
Industrial

BCS Series

Features

 Accuracy– ± 0.1% of full scale  Power– 9 VDC power adapter,
 Capacity– 1000mA with center positive and
3000 kg x 1 kg / 6000 lb x 2 lb 6V/4.0Ah lead acid rechargeable
5000 kg x 2 kg / 10,000 lb x 5 lb battery (both included). Remote
control operates on two AA
 Construction– Aluminium-casting batteries (included).
case, high intensity hook and  Display– 35 mm / 1.4" ultra-bright
shackle
LED
 Operator Keys– On/Off, Zero,
Tare, Hold

Specifications

Unit: kg, lb Zero Range: 4% full scale
Elongated Upper Shackle: Accommodates thick hooks Stable Time: ≤10 sec
Swivel Hook with Latch: Makes load connection easy and Overload: 100% F.S. + 9 divisions
secure
Overload Indication: Internal counter at +9 divisions F.S.
Bright LED Display: Has three adjustable brightness levels
for any environment Ultimate Safety Factor: 400% F.S.
Accumulator Function: Calculates total weight Safety Load: 150% F.S. of capacity
Factory Calibration: 39° latitude optimised Operating Temperature: -10° C to 40° C / 14° F to 104° F
Typical Battery Life: Depending on LED brightness and idle Operating Humidity: 20° C ≤90%
mode setting, battery works from 60 hrs to 200 hrs Scale Dimension (L x W x H):
Charging Time: Approximately 12 hrs; red LED charging, 255 mm x 210 mm x 440 mm / 10" x 8" x 17"
green finished Product Weight: 13 kg / 28.5 lb
Remote Functions: Zero, tare, hold, acc, del F1, F2, off, Packaging Dimension (L x W x H):
2nd 600 mm x 270 mm x 310 mm / 2" x 10" x 12"
Remote Distance: Minimum 10 m / 32′ Accuracy Class: GB/T 11883-2002 Class III
Auto-Off Function: Can be set from 0 to 60 minutes Certifications: UKCA, CE, CEC, EC Machinery Directive,
Tare Range: 100% full scale FCC compliant, Prop 65, RoHS 3, UL/CUL power
adapter, WEEE

Ship
Part Number Capacity Weight
816965006496 3000 kg x 1 kg / 6000 lb x 2 lb 13 kg
816965006502 5000 kg x 2 kg / 10,000 lb x 4 lb 13 kg Crane Scales
