Platform Scales Applications
Animal Weighing Shipping
Industrial Warehouse

PS3000-LCD
Features

 Accuracy– Within ±0.1%  Power– 9V 600mA universal power
 Capacity– supply with USA/UK/EU adapters
1500 kg x 0.5 kg / 3000 lb x 1 lb (included) or six AA batteries (not
 Construction– Powder coat paint included)
for corrosion protection. Mild steel  Display– Six large,easy-to-read
construction with safety tread plate 1.5” / 38 mm high digits, large
surface with fixed rubber mat. seven segment LCD with white
backlight
 Connection– 250 mm / 9.8” cable
fixed to indicator with connector,  Operator Keys– On/Off/Zero, Tare,
3 m / 9.8’ interface cable with Unit, Print, Hold, Accumulate/Total
connector

Indicator Specifications Floor Specifications

Unit: kg, lb, %, PCS Load Cell: Four OIML C3, waterproof-IP67, 350 Ohm shear
beam load cells
Functions: Weighing, Animal Averaging Hold, Percentage,
Check weighing, Counting, Accumulation, Print, Battery J-Box: ABS, weatherproof IP65 housing. Top access for
Saving accurate signal trim and cornering
Annunciators: -0-, motion, gross, net, tare, hold, pcs, %, HI/ Anti-Slip Rubber Mat: Easy on animal hooves, reduce
OK/LOW, battery, accumulation noise and risk of slipping (included)
Communication: USB (VCP) or RS-232 bidirectional full Platform:
duplex port. Optional COM cables. 150% overload protection
100% end loading capacity
Print Format: Configurable
Platform Dimension (L x W x H):
Operating Temperature: -10° C to 40° C / 14° F to 104° F 2000 mm x 1000 mm x 100 mm
Platform Scales
Product Dimension (L x W x H): 78.75” x 39.37” x 3.93”
135 mm x 250 mm x 165 mm / 5.25” x 9.75” x 6.5” Platform Weight: 120 kg / 264 lb
Packaging Dimension (L x W x H): Packaging Dimension (L x W x H):
254 mm x 393 mm x 228 mm / 10” x 15.5” x 9” 2050 mm x 1050 mm x 180 mm
Certifications: FCC compliant, Prop 65, ETL power adapter, 81” x 42” x 7.1”
UKCA, CE, RoHS 3, WEEE

Ship Weight
Part Number Capacity (platform + indicator)
810036380348 1500 kg x 0.5 kg / 3000 lb x 1 lb 275 + 2 kg

Accessories / Options
Part Number Description Ship Weight
810036380355 SBI 210 floor stand 5 kg
