FORCE MEASUREMENT EQUIPMENT

Force Control Switches- DynaSwitch

DynaSwitch Hardware Options

Dimensions inches (cm) D Rod End Connectors for Tension Rigging
B
A Dia. Model A B C D FITS DSW-1, DSW-2
DSW-1 0.25 0.75 1.25 0.38 Self-aligning, rod end connectors are normally
(.64) (1.9) (3.2) (1.0) mounted at right angles to each other providing
0.50 1.32 1.88 0.63 universal alignment under load. They can be
DSW-2
(1.27) (3.4) (4.8) (1.6) mounted parallel to the force beam on request.
Hardened Ball and Cup for Compression
E Use
Dimensions inches (cm)
Force Control Switches
Model A FITS All
DSW-1, DSW-2, DSW-4 0.45 (1.1) Heat-treated alloy steel. Cup is highly polished and
plated. Ball is held in place by spring clip held by
DSW-3, DSW-5 0.61 (1.6)
shoulder of cup. Slightly different configuration for
DSW-6, DSW-7 0.83 (2.1) high range switches.

F Lifting Eye for Tension Use
Dimensions inches (cm)
Model and Switch A FITS DSW-3, DSW-5
Switch B 4.34 (11.0) Hardened steel eye threads into force beam.
DSW-3 Oriented parallel to force beam unless otherwise
Switch C 5.24 (13.3)
specified. Orientation fixed by roll pin.
Switch B 4.34 (11.0)
DSW-5
Switch C 5.06 (12.9)
G Adapter, Shackle and Pin
Dimensions inches (cm)
Model DSW-2 DSW-3 DSW-4 DSW-5 DSW-6 DSW-7 FITS All except DSW-1
1.69 1.69 1.69 1.69 3.25 5.00 A hardened, forged steel shackle with adapter
A and pin for tension rigging of DynaSwitches.
(4.3) (4.3) (4.3) (4.3) (8.2) (12.7)
Shackles and similar fittings are installed at time
1.94 1.94 1.94 1.94 4.06 6.12
B of manufacture with the plane of the top fitting
(4.9) (4.9) (4.9) (4.9) (10.3) (15.5) lifting opening parallel to the beam length, and at
* Option C switch is 4.76 inch (12.1 cm) 4.19 4.13* 4.19 4.13† 7.12‡ 10.36 90° to the position of bottom fitting. Orientation
† Option C switch is 5.06 inch (12.85 cm) C (10.6) (10.5) (10.6) (10.5) (18.1) (26.3) fixed by roll pin.
‡ Option C switch is 8.38 inch (21.3 cm)

H Non-Swiveling Hook
Dimensions inches (cm) FITS DSW-3, DSW-5
Model and Switch A
A hardened, forged steel hook threaded to fit
Switch B 5.00 (12.7) 2,000 and 10,000 load switches only. Has spring
DWS-3
Switch C 5.00 (12.7) latch. Should be specified and installed at time
of manufacture before set points are adjusted.
Switch B 5.00 (12.7) Oriented parallel to force beam unless otherwise
DSW-5
Switch C 4.81 (12.2) specified. Orientation fixed by roll pin.
S Threaded Stud
Dimensions inches (cm)
FITS All except DSW-7
Model DSW-1 DSW-2 DSW-3 DSW-4 DSW-5 DSW-6
1.25 1.88 2.19 2.31 2.19* 2.31 For applications where conventional shackle
A or attachment eye cannot be used. Will
(3.2) (4.8) (5.6) (5.9) (5.6) (5.9)
accommodate yokes and other special fixtures.
B ¼-28 ½-20 7⁄8-14 ½-20 7⁄8-14 1¼-12 Heat treated alloy steel, secured by a roll pin.
* Option C switch is 2.00 inch (5.1 cm)
