Applications Floor Scales
Light Industrial Shipping
Livestock Warehouse
DCSB Floor Scale with SBI 521 LED Indicator
Features
Accuracy– NTEP 5000d, Class III Power– 6 volt 4 AH rechargeable Floor Scales
Capacity– internal lead acid battery with
110/220 AC internal transformer
5000 lb x 1 lb / 2500 kg x 0.5 kg
10,000 lb x 2 lb / 5000 kg x 1 kg Display– 0.7"/ 17 mm LED
Construction– Carbon steel Operator Keys–– Hold/Setup,
fabrication with ¼" / 6 mm thick Print/Func, N/G/Total, Unit/Data,
safety tread top plate & heavy Tare/Preset, Zero/On/Off
duty welded channel under Warranty– Includes three year
structure,150% overload protection parts on DCSB deck from time of
purchase. Consult factory.
Indicator Specifications Floor Specifications
Unit: lb, kg J-Box: IP65 ABS housing with top access for ease of
installation and service
Power: 6V 4 AH rechargeable internal lead
acid battery with 110/220 AC internal transformer Leveling Feet: Four top access holes for a quick installation
Serial Port 1: Full-duplex RS-232 Threaded Eye Bolts: Two threaded top access eye-bolt holes
for easy mobility and pit service
Serial Port 2: Full-duplex RS-232 or half-duplex RS-485
Corner Protection: Closed corners to prevent damage to
Digital Calibration: Front panel calibration and configuration leveling feet while installing the scale
Functions: Motion, zero, net, gross, tare, total, lb, kg, %, pcs, Interface Cable Length: 15' / 4.5 m with tinned leads
oz, peak/hold, hi, ok, lo, ac/chg (included)
Display: Up to 50,000 graduations Load Cell: NTEP approved, IP67 potted 350 ohm +/- 3.5Ω
Certifications: NTEP at 5,000d, Class III, CC #11-119 Overload Protection: 150% of rated capacity
Accessories: See DCSB Series (deck only) and SBI 521
Indicator page
Ship
Part Number Model Platform Size (L x W) Capacity Weight
816965005352 DCSB4848-05 48″ x 48″ / 1219 x 1219 mm 5000 lb x 1 lb / 2500 kg x 0.5 kg 320 lb
810036380096 DCSB5959-05 59″ x 59″ / 1500 x 1500 mm 5000 lb x 1 lb / 2500 kg x 0.5 kg 495 lb
816965005376 DCSB4848-10 48″ x 48″ / 1219 x 1219 mm 10,000 lb x 2 lb / 5000 kg x 1 kg 315 lb
810036380102 DCSB5959-10 59″ x 59″ / 1500 x 1500 mm 10,000 lb x 2 lb / 5000 kg x 1 kg 475 lb
Note: Multiple packs of five+ are available upon request.
