FORCE MEASUREMENT EQUIPMENT
Mechanical X Force Gauges
Model X-C (Compression) Force Gauge
A
Part Part A B C D E F G H J J1 K
Number Pounds Number Kilograms in (mm) in (mm) in (mm) in (mm) in (mm) in (mm) in (mm) in (mm) in (mm) in (mm) in (mm)
30386-0035 50 x .05 - - 4.25 1.00 0.50 2.50 2.06 2.00 2.25 0.38 1/4-28 1/4-28 2.94
(107.9) (25.4) (12.7) (63.5) (52.3) (50.8) (57.1) (9.6) (74.6)
30386-0043 100 x 1 - 50 x 0.5 4.25 1.00 0.50 2.50 2.06 2.00 2.25 0.38 1/4-28 1/4-28 2.94
30386-0159* 30386-0183* (107.9) (25.4) (12.7) (63.5) (52.3) (50.8) (57.1) (9.6) (74.6)
30446-0033 250 x 2.5 - 100 x 1 4.25 1.00 0.50 2.50 2.06 2.00 2.25 0.38 1/4-28 1/4-28 2.94
30446-0090* 30446-0181* (107.9) (25.4) (12.7) (63.5) (52.3) (50.8) (57.1) (9.6) (74.6)
30446-0017 500 x 5 - 200 x 2 4.25 1.00 0.50 2.50 2.06 2.00 2.25 0.38 1/4-28 1/4-28 2.94
30446-0074* 30446-0082* (107.9) (25.4) (12.7) (63.5) (52.3) (50.8) (57.1) (9.6) (74.6)
30444-0019 1,000 x 10 - 500 x 5 4.25 1.00 0.50 2.50 2.06 2.00 2.25 0.38 1/2-20 1/2-20 2.94
30444-0050* 30444-0068* (107.9) (25.4) (12.7) (63.5) (52.3) (50.8) (57.1) (9.6) (74.6)
30388-0017 2,000 x 20 - 1000 x 10 4.75 1.00 0.50 3.00 2.25 2.50 2.75 0.38 1/2-20 1/2-20 3.44
30388-0058* 30388-0066* (120.6) (25.4) (12.7) (76.1) (57.1) (63.5) (69.8) (9.6) (873)
30389-0016 5,000 x 50 - 2000 x 20 4.75 1.00 0.50 3.00 2.25 2.50 2.7 0.38 1/2-20 1/2-20 3.44
30389-0057* 30389-0065* (120.6) (25.4) (12.7) (76.1) (57.1) (63.5) (69.8) (9.6) (8.73)
B
Part Part A B C D E F G H J J1 K
Number Pounds Number Kilograms in (mm) in (mm) in (mm) in (mm) in (mm) in (mm) in (mm) in (mm) in (mm) in (mm) in (mm)
30423-0014 10,000 x 100 - 5000 x 50 5.87 1.87 0.94 3.94 2.75 3.00 3.62 0.75 7/8-14 7/8-14 4.50
30423-0055* 30423-0063* (149.0) (47.5) (23.9) (100.0) (69.8) (76.1) (91.9) (19.0) (114.2)
30449-0014 25,000 x 250 - 10,000 x 100 6.56 2.38 1.18 4.68 3.31 3.63 3.62 1.00 1-14 1 1/4-12 5.50
30449-0055* 30449-0063* (166.5) (60.4) (29.9) (118.8) (84.0) (92.1) (91.9) (25.4) (139.6)
Model X-ST (Tension) and Model X-PP (Push-Pull) Gauges
C
Part Part Part A B C D E F
Number Tension lb Number Tension kg Part Number Push-Pull lb Number Push-Pull kg in (mm) in (mm) in (mm) in (mm) in (mm) in (mm)
- - - 25 x 0.25 - - - - 4.25 1.00 0.50 2.50 2.06 2.03
30443-0176* (107.9) (25.4) (12.7) (63.5) (52.3) (51.5)
30443-0044 100 x 1 30443-0093 50 x 0.5 30795-0014 50-0-50 - - 4.25 1.00 0.50 2.50 2.06 2.03
30443-0150* 30443-0184* (107.9) (25.4) (12.7) (63.5) (52.3) (51.5)
30445-0034 250 x 2.5 - 100 x 1 30796-0013 125-0-125 30796-0021 50-0-50 4.25 1.00 0.50 2.50 2.06 2.03
30445-0109* 30445-0182* (107.9) (25.4) (12.7) (63.5) (52.3) (51.5)
30445-0018 500 x 5 30445-0026 200 x 2 - - - - 4.25 1.00 0.50 2.50 2.06 2.03
30445-0083* 30445-0091* (107.9) (25.4 (12.7) (63.5) (52.3) (51.5)
30276-0012 1,000 x 10 - 500 x 5 30798-0011 500-0-500 4.25 1.00 0.50 2.50 2.06 2.03
30276-0053* 30276-0061* 30798-0029 250-0-250 (107.9) (25.4) (12.7) (63.5) (52.3) (51.5)
30440-0013 2,000 x 20 - 1000 x 10 - - - - 4.75 1.00 0.50 3.00 2.25 2.19
30440-0054* 30440-0062* (120.6) (25.4) (12.7) (76.1) (57.1) (55.6)
D
- 5,000 x 50 - 2000 x 20 30800-0017 2,500-0-2,500 30800-0025 1000-0-1000 4.75 1.50 0.75 3.00 2.25 2.66
30442-0052* (120.6) (36.1) (19.0) (76.1) (57.1) (67.5)
- - 5000 x 50 - - - - 5.88 1.88 0.94 3.94 2.75 3.00
30441-0053* 10,000 x 100 30441-0061* (149.2) (47.7) (23.9) (100.0) (69.8) (76.1)
*Max hand
