P. 35

Applications                                                                     Medical - Physician
             Health Care           Health Clubs




            MS140-300 with SBI 140 LCD Indicator

            Features
             Accuracy– Within ±0.09%            Power– Four AAA batteries or
             Capacity– 660 lb x 0.2 lb /          9 VDC, 600mA wall mount adapter
                                                   (both included)
               660 lb x 5 oz / 300 kg x 0.1 kg
             Construction– Stainless steel      Display– Five digit 0.65″ / 17 mm
                                                   digits with seven segment LCD
               weighing surface with mild steel
               foam covered handrails. Rigid     Operator Keys– On/Off/Zero,
               base design.                        Tare, Unit, Hold/Print












            Specifications

            Unit: lb, lb/oz, kg                                 Platform Dimension (L x W x H):
                                                                   20.5″ x 20.5″ x 2.5″ / 520 mm x 520 mm x 65 mm
            Serial Port: One full duplex RS-232 with cable
                                                                Indicator Dimension (L x W x H):
            RS-232: Supplied complete with 10′ cable (nine pin to nine pin   6.5″ x 1.2 x 3.2″ / 165 mm x 30 mm x 81 mm
               type connector, bi-directional full duplex)
                                                                Packaging Dimension (L x W x H):
            Integrated Wheel Kit: For easy portability             46″ x 25″ x 6″ / 1168 mm x 635 mm x 152 mm
            Weight Hold: May be used to freeze and store the displayed   Packaging Contents: Manual, platform, three piece handles,
               weight so that you may attend to the patient's needs  power supply, RS-232 cable, indicator, three hex wrenches
            Operating Temperature: 41° F to 95° F / 5° C to 35° C   and pull through string
            Scale Dimension (L x W x H):                        Certifications: FCC compliance, ETL power adapter
               20.5″ x 20.5″ x 44.25″ / 520 mm x 520 mm x 1135 mm

                                                       Ship                                                              Medical  Scales
             Part Number   Capacity                   Weight
             816965004829  660 lb x 0.2 lb / 300 kg x 0.1 kg  55 lb























                                                                                                                        35
